| Model | Indoor unit | 7.1KW |
| Indoor unit(Air Guard Series) | 7.1KW (H) |
| Capacity | Nominal Cooling | KW | 7.1 |
| Nominal Heating | KW | 8 |
| Electrical Parameters | Power supply | Ph/V/Hz | 1/220～240/50/60 |
| Performance | Air flow（H/M/L/Q） | m3/h | 1260/1070/820/680 |
| Sound power level（H） | dB(A) | 55 |
| Sound pressure level(H/M/L/Q） | dB(A) | 36/33/29/26 |
| Installation | External dimensions(W/D/H) | mm | 840/840/204 |
| Shipping dimensions(W/D/H) | mm | 990*990*310 |
| Net/Shipping weight | kg | 27/32 |
| Refrigerant liquid pipe | mm | 9.52 |
| Refrigerant gas pipe | mm | 15.88 |
| Controller | optional(wireless) | YR-HQS01 |
| optional(wired) | YR-E17A |
| Panel | Model |
| PB-950KB(standard panel) |
| External dimensions(W/D/H) | mm | 950*950*50 |
| Shipping dimensions(W/D/H) | mm | 1013*1025*123 |
| Net/Shipping weight | kg | 6.5/9.5 |
